Industrial Enclosure Selection Page

AKIII Series

The Unique AKIII Enclosure
with Patented Air Ventilation System

The patented Air Ventilation elements avoid condensate water while preserving the high protection class IP65. Occurring condensate is transported out of the enclosure immediately via air exchange. The continuous and high air exchange allows the interior air to mix constantly with the environmental air and transports the moisture outward. Even environments with nearly constant humidity and temperature possess air exchange, since the air on the interior of the enclosure warms due to the fittings. The individual components of the ventilation elements mainly consist of the rotating cover (rear side of box) and the 10µm filter element integrated on the inside of the box.

Advantages of Air ventilation elements

  • Prevention of condensate water while preserving the high protection class IP65
  • High air exchange rate
  • 100% pressure compensation
  • Foreign object protection
  • Maintenance-free
Drawing and Data Files (If files do not automatically open, save to disk and than open.)

AK-F 14 – Polystyrene and Polycarbonate - 315 x 300 x 155 mm (12.4 x 11.8 x 6.1 in)
3D STEP Specification pages
AK-F 28 – Polystyrene and Polycarbonate - 315 x 450 x 155 mm (12.4 x 17.7 x 6.1 in)
3D STEP Specification pages
AK-F 42 –– Polystyrene and Polycarbonate - 315 x 600 x 155 mm (12.4 x 23.6 x 6.1 in)
3D STEP Specification pages
AK-F 56 – Polystyrene and Polycarbonate - 315 x 750 x 155 mm (12.4 x 29.5 x 6.1 in)
3D STEP Specification pages
AK-F 14 Plus – Polystyrene and Polycarbonate – 315 x 450 x 155 mm (12.4 x 17.7 x 6.1 in)
3D STEP Specification pages
AK-F 28 Plus – Polystyrene and Polycarbonate – 315 x 600 x 155 mm (12.4 x 23.6 x 6.1 in)
3D STEP Specification pages
AK-F 42 Plus – Polystyrene and Polycarbonate – 315 x 750 x 155 mm (12.4 x 29.5 x 6.1 in)
3D STEP Specification pages
