ATEX ENCLOSURES



Type CA...Ex, Aluminium



Type CPG...Ex, Polyester grey and Type CPS...Ex, Polyester black

Solenoid Locking Safety Switch Solenoid Locking Safety Switch

Thanks to its robust design and high corrosive resistance, the CA aluminium enclosure range delivers high mechanical strength and are particularly suitable for potentially explosive atmospheres. They can also be used as terminal boxes or control enclosures for connection of electrical components. All built-in components must conform to the relevant approvals. Only materials that correspond to the temperature range T6 required for Ex enclosures are used in these enclosures and components. The minimum type of protection rating of all enclosures and screw connections is IP 64.

The enclosures come with captive cover screws, optional factory fitted external hinges are also available. Either an EPDM or silicone seal can be used. BERNSTEIN CA aluminium enclosures are finished RAL 7001 as standard.

ATEX  standard enclosures

  • specifications
  • Suitable for Zone 1, 2, 22

Thanks to its robust design and high corrosion resistance, the CPG Grey glass-fibre reinforced polyester enclosure range delivers high mechanical protection and are particularly suitable for potentially explosive atmospheres.  They can also be used as terminal boxes or control enclosures for connection of electrical components. All built-in components must conform to the relevant approvals. Only materials that correspond to the temperature range T6 required for Ex enclosures are used in these enclosures and components. The minimum type of protection rating of all enclosures and screw connections is IP 64. The enclosures come with captive cover screws, optional factory fitted external hinges are also available. Either an EPDM or silicone seal can be used. Bernstein CPG polyester enclosures have a grey RAL 7000 self colour finish as standard.

ATEX  standard enclosures

  • Component mounting and wiring of enclosures according to customer specifications
  • Suitable for Zone 1, 2, 22


Product Advantages:

  • Enclosure for high mechanical strength
  • High corrosion and impact resistance due to high-quality powder coating - Standard in RAL 7001 (silver grey)
  • Other RAL colours available on request

Design Layout

  • Protection type IP 65 afterafter EN60079-0
  • Protection type IP 66 nach EN60529
  • Width: 64 - 310 mm
  • Lengt: 58 - 600 mm
  • Height: 36 - 180 mm
  • TÜV 03 ATEX 2136
  • TÜV 10 ATEX 555682 U for Enclosures


Product Advantages:

  • Enclosure for high mechanical strength
  • Very high corrosion resistance
  • Excellent for external applications
  • Standard colour RAL 7000 (grey) and RAL 9005 (black)

Design Layout

  • Protection type IP 64 after EN60079-0
  • Protection type IP 66 after EN60529
  • Width: 75 - 405 mm
  • Length: 80 - 600 mm
  • Height: 50 - 165 mm
  • TÜV 03 ATEX 2153X
  • TÜV 08 ATEX 554061 U for blank enclosure
